9GB/IE/NI/CY/MT
33
Screw terminal of neutral mains
connection
34
Screw terminal for protective
conductor
35
Cover for basic settings
36
4 screws for cover for basic
settings
37
Button Update
38
Cover detect switch
39
Rotary switch for Smart Meter
address
40
Rotary switch for Smart Meter
address x10
41
Master/Slave rotary switch
42
Rotary switch max. charge
current
43
USB Port Update
Note: The use of the term “product”
or “device” in the following text
refers to the charger
1
named in
these operating instructions.
z Technical Specifications
Model: USWB 11 A1
Operating temperature:
-25 °C – 50 °C
Input voltage: 230 V~ 50 Hz
Max. input current: 16 A
Output voltage: 230 V~ 50 Hz
Max. output current: 16A
Max. charging capacity:
3.7 kW (1 Ph)
11 kW (3 Ph)
Total length: 500 cm
Housing protection type: IP65
Residual current detection: 30 mA AC
Residual current detection: 6 mA DC
Appliance class: I
Output plug: T2
(in accordance with EN 62196-2)
Changes to technical and visual
aspects of the product may be made
as part of future developments without
notice. Accordingly, no warranty is
offered for the physical dimensions,
information and specifications
in these operating instructions.
The operating instructions cannot
therefore be used as the basis for
asserting a legal claim.
z Safety instructions
PLEASE READ
THROUGH THE
INSTRUCTION MANUAL
CAREFULLY BEFORE USE.
THESE FORM PART OF THE
PRODUCT AND MUST BE
AVAILABLE AT ALL TIMES!
This section covers the basic
safety instructions applicable
when working with the device.
Personal safety:
Keep children and animals
away from the charger
1
.
Children must be supervised
to ensure that they do not play
with the device.
Within the working area, the
user is responsible for any
