87
6. Pull out the wornout brake pads and
insert the new brake pads. Insert the
disc pad lock pin and ß clip.
7. Add fresh DOT 4 brake uid and
pump the rear brake pedal till the
brake is loaded.
Steps for Front Brake Pad Replacement
1. Check the brake pad wear. If the
brake pad is worn out, the pad needs
to be replaced.
2. Remove the lock clip using a nose
plier and remove the brake pad lock
pin using a T30 Torx key and remove
the retainer spring and brake pads.
To Next Page
