Press TRIG MENU type , select delay by the Multipurpose knob. You can also switch trigger type by
consecutively pressing the type key, then press the Multipurpose knob to confirm.
At this time, the trigger setting information is displayed at the upper right corner of the screen,
the trigger type is delay, the trigger source is CH2, and the low level of the trigger level is 0.00V.
Delay Trigger Menu
Source 1:
Press the source 1 key to select any of CH1, CH2, CH3, and CH4. The currently selected source is displayed at the upper
right corner of the screen.
Note: Only selecting the channel with connected signals as a trigger source can obtain a stable trigger.
Edge 1:
Press the edge 1 key to select the trigger edge: rising edge, and falling edge.
(1) Rising edge: Set to trigger at the rising edge of source 1.
(2) Falling edge: Set to trigger at the falling edge of source 1.
Source 2:
Press the source 2 key to select any of CH1, CH2, CH3, and CH4. The currently selected source is displayed at the upper
right corner of the screen.
Note: Only selecting the channel with connected signals as a trigger source can obtain a stable trigger.
Edge 2:
Press PgDn edge 2 key to select the trigger edge: rising edge, and falling edge.
(1) Rising edge: Set to trigger at the rising edge of source 2.
(2) Falling edge: Set to trigger at the falling edge of source 2.
Condition:
Press PgDn condition to select: ">", "<", "< >", :> <".
(1) >: Triggers when the time difference (△T) between the edge set by source 1 and the edge set by source 2 is greater
than the set time limit.
(2) <: Triggers when the time difference (△T) between the edge set by source 1 and the edge set by source 2 is less than
the set time limit.
(3) < >: Triggers when the time difference (△T) between the edge set by source 1 and the edge set by source 2 is greater
than the set lower time limit and less than the set upper time limit.
(4) > <: Triggers when the time difference (△T) between the edge set by source 1 and the edge set by source 2 is less
than the set lower time limit and greater than the set upper time limit.
Time:
Press PgDn time to choose: normal, upper time limit, and lower time limit.
(1) Normal: When the trigger condition is ">" or "<", this key can only be normal.
(2) Upper time limit: User can select this option when the trigger condition is "< >" or "> <".
(3) Lower time limit: User can select this option when the trigger condition is "< >" or "> <".
Setting:
Press the PgDn key and adjust the Multipurpose knob to set the time.
5.9 Timeout Trigger
Select the timeout trigger to trigger the signal that the time interval (△T) from the rising edge (or falling edge) of the input
signal crosses the trigger level to the adjacent falling edge (rising edge) crosses the trigger level is greater than the set
timeout time. As shown in the following figure.
29
