Rotary Switch
Rotary
Switch
Position
Function
DC voltage measurement.
AC voltage measurement.
DC Current Measurement
Diode test.
Continuity test.
Resistance measurement.
V
V
A
Automotive engine tach (rotation speed)
testing (Displayed Reading x 10), Unit: rpm
RPM x 10
DWELL Automotive ignition dwell testing, Unit: degree
Below table indicated for information about the rotary
switch positions.
Model UT105: OPERATING MANUAL
