UNI-T UT105 User Manual

Display Symbols (see figure 2)
( figure 2)
No. Symbol Meaning
1
The battery is low.
Warning: To avoid false readings,
which could lead to possible electric
shock or personal injury, replace the
battery as soon as the battery
indicator appears.
2
Indicates negative reading.
4
Test of diode.
5
The continuity buzzer is on.
6
Date hold is active.
7
Indicator for AC voltage or current.
The displayed value is the mean
value.
3
AC
Connect
Terminal
Indicator of connecting test leads
into different input terminals.
Model UT105: OPERATING MANUAL
15
1
2
3
4
5
6
7
8

UNI-T UT105 Specifications

General

Product type	Digital multimeter
AC voltage range	2 - 750 V
DC current range	0.2 - 10 A
DC voltage range	0.2 - 1000 V
Dimensions (WxDxH)	88 x 39 x 179 mm
Battery voltage	9 V

Weight and Dimensions

Weight	352 g
