Model UT60H: OPERATING MANUAL
20
Measurement Operation(6)
E. Measuring Resistance (see figure 5)
Warning
To avoid harms to you, please do not attempt to input
voltage higher than 60V DC or 30V rms AC.
To avoid damages to the Meter or to the devices under
test, disconnect circuit power and discharge all the
high-voltage capacitors before measuring resistance.
(figure 5)
The resistance ranges are:400Ω, 4kΩ, 40kΩ,400kΩ,
4MΩand 40MΩ.
To measure resistance, connect the Meter as follows:
1. Insert the red test lead into the Ω terminal and the
black test lead into the COM terminal.
2. Set the rotary switch to Ω ; Press SELECT
button to select Ω measurement mode.
3. Connect the test leads across with the object being
measured.
The measured value shows on the display.
