C. Measuring Resistance (see figure 5)
Warning
To avoid damages to the Meter or to the devices under
test, disconnect circuit power and discharge all the
high-voltage capacitors before measuring resistance.
To avoid harms to you, please do not attempt to input
voltages higher than 60V DC or 30V AC.
To measure resistance, connect the Meter as follows:
20
Model UT803: OPERATING MANUAL
Insert the red test lead into the terminal and the
black test lead into the COM terminal.
Set the rotary switch to , press SELECT
button to select measurement mode.
Connect the test leads across with the object being
measured. The measured value shows on the display.
1.
2.
3.
(Figure 5)

UNI-T UT803 Specifications

General

Backlight	Yes
Product type	Digital multimeter
Frequency range	6 - 60000 kHz
AC current range	0.06 - 10 A
DC voltage range	0.6 - 1000 V
Capacitance range	6 - 6000 nF
Statistic function	Maximum, Minimum
Resolution (frequency)	100000 Hz
Resolution (AC current)	6000 µA
Basic accuracy (frequency)	±(0.1%+3)
Basic accuracy (DC current)	±(0.5%+3)
Basic accuracy (DC voltage)	±(0.3%+2)
Basic accuracy (resistance)	±(0.5%+2)
Basic accuracy (capacitance)	±(2%+5)
Temperature measurement range	-40 - 1000 °C
Dimensions (WxDxH)	310 x 240 x 105 mm
Battery voltage	1.5 V

Weight and Dimensions

Weight	2400 g
