UNI-T UT803 User Manual

Remarks:
At 6nF, 60nF and 600nF Range: reading must subtract the test lead open circuit capacitance value.
45
Model UT803: OPERATING MANUAL
H. Capacitance
l
Range Resolution Accuracy Overload Protection
0.001nF
0.01nF
0.1nF
0.001µF
0.01µF
0.1µF
0.001mF
6nF
60nF
600nF
6µF
60µF
600µF
6mF
(2.5%+5)
(2%+5)
(3%+4)
(5%+4)
250V rms

UNI-T UT803 Specifications

General

Backlight	Yes
Product type	Digital multimeter
Frequency range	6 - 60000 kHz
AC current range	0.06 - 10 A
DC voltage range	0.6 - 1000 V
Capacitance range	6 - 6000 nF
Statistic function	Maximum, Minimum
Resolution (frequency)	100000 Hz
Resolution (AC current)	6000 µA
Basic accuracy (frequency)	±(0.1%+3)
Basic accuracy (DC current)	±(0.5%+3)
Basic accuracy (DC voltage)	±(0.3%+2)
Basic accuracy (resistance)	±(0.5%+2)
Basic accuracy (capacitance)	±(2%+5)
Temperature measurement range	-40 - 1000 °C
Dimensions (WxDxH)	310 x 240 x 105 mm
Battery voltage	1.5 V

Weight and Dimensions

Weight	2400 g
