UNI-T UT803 User Manual

30
H. Temperature Measurement (see figure 10)
Warning
To avoid harms to you, please do not attempt to input
voltages higher than 60V DC or 30V AC.
To measure temperature, connect the Meter as follows:
Model UT803: OPERATING MANUAL
1.
2.
3.
4.
Set the rotary switch to
0
C to measure degree celsius
temperature or Hz
0
F and press SELECT button to
select
0
F measurement mode to measure Fahrenheit
temperature.
Insert the multi-purpose socket into the corresponding
Hz and COM terminal.
Insert the temperature probe to the corresponding
input terminal of the multi-purpose socket.
Place the temperature probe to the object being
measured. The measured value shows on the display
after few seconds.
(Figure 10)

UNI-T UT803 Specifications

General

Backlight	Yes
Product type	Digital multimeter
Frequency range	6 - 60000 kHz
AC current range	0.06 - 10 A
DC voltage range	0.6 - 1000 V
Capacitance range	6 - 6000 nF
Statistic function	Maximum, Minimum
Resolution (frequency)	100000 Hz
Resolution (AC current)	6000 µA
Basic accuracy (frequency)	±(0.1%+3)
Basic accuracy (DC current)	±(0.5%+3)
Basic accuracy (DC voltage)	±(0.3%+2)
Basic accuracy (resistance)	±(0.5%+2)
Basic accuracy (capacitance)	±(2%+5)
Temperature measurement range	-40 - 1000 °C
Dimensions (WxDxH)	310 x 240 x 105 mm
Battery voltage	1.5 V

Weight and Dimensions

Weight	2400 g
