Note
The testing environment must between 18
0
C to 28
0
C
to ensure accuracy especially when measuring low
temperature.
Different reading may be obtained when testing room
environment under short or open circuit situation,
then short-circuited reading shall be considered as
the correct reading.
The included point contact temperature probe can
only be used under 230
0
C. For any measurement
higher than that, the rod type temperature probe
must be used instead.
Model UT803: OPERATING MANUAL
When temperature measurement has been
completed, disconnect the connection between the
temperature probe, multi-purpose socket and the
circuit under test, and remove the temperature probe
away from the input terminals of the multi-purpose
socket, and remove the multi-purpose socket away
from the input terminals of the Meter.
l
l
l
l

UNI-T UT803 Specifications

General

Backlight	Yes
Product type	Digital multimeter
Frequency range	6 - 60000 kHz
AC current range	0.06 - 10 A
DC voltage range	0.6 - 1000 V
Capacitance range	6 - 6000 nF
Statistic function	Maximum, Minimum
Resolution (frequency)	100000 Hz
Resolution (AC current)	6000 µA
Basic accuracy (frequency)	±(0.1%+3)
Basic accuracy (DC current)	±(0.5%+3)
Basic accuracy (DC voltage)	±(0.3%+2)
Basic accuracy (resistance)	±(0.5%+2)
Basic accuracy (capacitance)	±(2%+5)
Temperature measurement range	-40 - 1000 °C
Dimensions (WxDxH)	310 x 240 x 105 mm
Battery voltage	1.5 V

Weight and Dimensions

Weight	2400 g
