UTD1000 User Manual

Press [MATH] then [F1] select FFT as the mathematics type. The menu is as shown in Table 2-16.

Table 2-16 FFT function menu

Explanatory Note

Set Hanning window function.

Set Hamming window function.

Set Blackman window function.

Set Rectangle window function.

Set A as the mathematics waveform.

Set B as the mathematics waveform.

Display the frequency per division (f/div) of the current horizontal axis.

Display the current FFT range and adjust with the jog dial.

You can move the mathematics waveform with the jog dial.

Setup

Hanning

Hamming

Blackman

Rectangle

305.1 mHz-

244.1MHz

5mV-50V

Function Menu

FFT

Signal source

Horizontal range

Vertical range

Move
