UTD1000 User Manual
UTD1000 Oscilloscopes offer a user-friendly front panel with clear indications to allows access to all basic functions
for easy operation. The scaling and position buttons for all channels are optimally arranged for direct view operation.
As design is based on the controls of traditional instruments, users can use the new units without spending
considerable time in learning and familiarizing with operation. For faster adjustment to ease testing, there is an
[AUTO] key to instantly display the appropriate waveform and range position. Apart from being extremely user-friendly,
UTD1000 Oscilloscopes have the high performance indicators and superb functions required for speedy execution
of measurement tasks. The strong trigger and analytical functions make it easy to acquire and analyse waveforms,
while the sharp and clear LCD and mathematics functions ensure clear observation and reliable analysis of signal
conditions.
The performance features listed below will explain why the UTD1000 series can fully satisfy your testing and
measurement requirements :
● Dual channels; vertical deflection width range : 5mV/div – 50V/div
● Automatic waveform and status configuration
● Storage of waveforms, setups and interfaces; waveforms and setups reproduction
● Screen copy function
● Fine window extension; precise analysis of waveform details and overview
● Automatic measurement of 27 waveform parameters
● Cursor measurement function
● Unique waveform recording, storage and replay function
● USB interface that supports USB2.0
● HD color 5.7 inch LCD panel at 320 x 240 pixel aspect ratio
