Warning: Pleas e confirm safety grounding of digital
storage oscillograph to avoid dangers
.
2. Signal access of digital storage oscillograph is
double-channel input for UTD2000/3000 series
digital storage oscillograph. There is also 1 EXT
TRIG INPUT channel. Please connect signals
according to following steps
:
(As shown in Figure 1-5), connect probe of
digital storage oscillograph to CH1 input terminal
and s et attenuation ratio switch on probe to 10×
Á
Figure 1 5 Setup of attenuation ratio switch o
n
probe
㧙
ķ
ˊ
