UNI-T UTD2102e Series

UTD2000 Series User Manual
59
Backlight intensity (Typical) 300nit
Interface function:
Standard configuration 1 USB OTG
General Technical Specification
Probe compensator output
Output voltage (Typical) About 3Vpp, when the load≥1MΩ
Frequency (Typical) 1kHz
Power Source
Power voltage
100V～240VAC
RMS
，50/60Hz，CAT II
Power consumption ≤100VA
Fuse 1.6AL 250V (Fuse is located inside the instrument housing)
Environment Specifications
Temperature Range
Operating Temperature Range: 0℃~+40℃
Storage Temperature Range: -20℃~+60℃
Cooling Build-in cooling fan
Operating Humidity Range
<35℃: ≤90%RH
35℃~40℃: ≤60%RH
Operating Altitude Below 3,000m
Mechanical specifications
Size 306mm(W)×147mm(H)×122mm(D)
Weight
UTD2000L&UTD2000EX： Excluding package：2.5kg Including package：3.5kg
UTD2102e：Excluding package：2.5kg Including package：3.5kg
I P protection
IP2X
Recommended calibration Interval
The recommended calibration interval is every one year
