38
BMM parameters
Code Symbol Description Unit Min. Max. Imp. Fab.
803 Srv Enabled Services 0 1
48
ChSet
CH#1: Set-point °C 20 85
784 BC Local BUS address 0 7
816 MI Modbus Address 1 127
817 MT Modbus Time-out sec. 0 240
896 TU °Fahrenheit 0 1
799 AC Input 0/10V 0 2
376 DI1 Programmable Input #1 0 3
322 Po Pump: Post-circulation min. 1 30
341 PL Pump: Minimum Control % 0 100
313 Pr Pump: Maximum Control % 0 100
31 HL CH#1: Minimum Set-point °C 20 85
39 HH CH#1: Maximum Set-point °C 20 85
792 CHP CH: Max. Modulation % 0 100
619 IG Ignition Modulation % 30 80
527 PU Fan: PPR 0 3
486 FP Fan: Reg. Prop. 0 50
487 FI Fan: Reg. Int. 0 50
489 Fpl Fan: PWM min. % 5 15
337 Fr Modulation Gradient % 1.0
100.0
526 FU Fan: Max Max. Hz 50 120
319 FH Maximum Modulation % 1.0
100.0
346 FL Minimum Modulation % 1.0
100.0
314 Sb Modulation on Standby % 0 100
620 IP Postpurge: Fan % 0 100
617 IGL Ignition: Mod. Min. % 0 100
618 IGH Ignition: Mod. Max. % 0 100
353 HP CH PID: Proportional °K 0 50
354 HI CH PID: Integrative 0 50
478 Hd CH PID: Derivative 0 50
34 HY Burner Hysteresis °K 5.0 20.0
336 HS Temperature Gradient
°C/min
0 30
483 rP
Gen: Temp. Max Dierential
°C 0.0 50.0
380 Al1 Programmable Sensor #1 0 2
777 AFC APS Control 0 2
805 LV Mains Voltage V 100 240
2590 Burner Output kW 10 1000
( ) LPG values
3.15 - PROGRAMMING THE OPERATING PARAMETERS
ATTENTION!
Function reserved for After Sale
Service Centres only.
ATTENTION!
These functions are explained
in chapter 2.8 (DEVICES menu)
of the Uy P. TOUCH CONTROL
installation and maintenance
manual.
