2.4.1 - TECHNICAL DATA ACCORDING TO ErP DIRECTIVE
MODULEX EXT 100 EXT 116 EXT 150 EXT 200 EXT 250 EXT300 EXT 350
Element Symbol Unit
E󰀨ective nominal output Prated kW 97 113 146 195 244 294 342
Seasonal energy e󰀩ciency of central
heating
ƞ
s % 92
Season e󰀩ciency class for
heating
A A A A A A A
For boilers for central heating
and mixed boilers:
e󰀨ective heat output
E󰀨ective heat output with
high temperature capacity
(Tr 60 °C / Tm 80 °C)
P
4 kW 97.2 112.9 146.1 195.2 244.5 294.0 341.7
Rated heat output e󰀩ciency
with high temperature capacity
(Tr 60 °C / Tm 80 °C)
ƞ
4 % 88 87.7 87.7 87.7 88.1 88.3 88.5
E󰀨ective output at 30% of the rated heat
output with low temperature
capacity (Tr 30 °C)
P
1 kW 32.2, 37.4 49.3 64.4 80.5 96.6 112
Performance at 30% of the rated heat
output with low temperature
capacity (Tr 30 °C)
ƞ
1 % 96.7
Boiler with output range
adjustment: YES / NO
NO NO NO NO NO NO NO
Auxiliary electricity consumption
With a full load elmax kW 0.145 0.165 0.210 0.290 0.362 0.435 0.507
With a partial load elmin kW 0.040
Standby mode P
SB kW 0.010
Other elements
Heat dispersion on standby P
stb kW 0.787 0.94 0.94 0.98 1.10 1.15 1.39
Nitrogen oxides emissions ref. PCS NOx
Mg/kWh 49
NOx class 6
Annual electricity consumption Q
HE GJ 306 355 459 612 766 920 1069
For mixed heating appliances
Declared load prole - - - - - - -
Water heating
energy e󰀩ciency
ƞ
wh % - - - - - - -
Daily consumption of electricity Qelec kWh - - - - - - -
Daily consumption of fuel Qfuel kWh - - - - - - -
Internal sound power level Lwa dB (A) - - - - - - -
Annual electricity consumption AEC kWh - - - - - - -
Annual fuel consumption AFC GJ - - - - - - -
Seasonal DHW e󰀩ciency class
- - - - - - -
