UNION SWITCH & SIGNAL GENISYS II System Hardware Installation
2-14 August 1999 SM-6900B Rev. 0.0
T
ABLE
2-3. GENISYS II PC B
OARD
C
ONNECTOR
C
OMPONENTS AND
T
OOLS
Fig. 2-6
Item
Description US&S Part No. Comments/Vendor Part No.
1 Connector housing assembly
48-pin
96-pin
J709146-1105
J709146-1104
Used with most PCBs.
Used with non-vital I/O PCB N17061501.
2 Connector receptacle
48-pin
96-pin
J709146-0452
J709146-0922
--
3 Receptacle mounting screw J525400-0001 Mounts both 48-pin or 96-pin receptacle.
4 Guide
48-pin
96-pin
J709146-1106
J709146-1107
--
5 Wire crimp contact
48-pin, #16 to #20 wire
48-pin, #20 to #26 wire
96-pin, #20 to #28 wire
J709146-0453
J709146-0853
J709146-0921
Harting 09-06-000-8482
Harting 09-06-000-8481
Harting 09-06-000-8484
-- Crimp tool, for:
48-pin, #16 to #20 wire
48-pin, #20 to #26 wire
96-pin, #20 to #28 wire
--
Harting tool 09-99-000-0077
Harting tool 09-00-000-0076
Harting tool 09-00-000-0075
-- Extraction tool, for:
48-pin, #16 to #20 wire
48-pin, #20 to #26 wire
96-pin, #20 to #28 wire
--
Harting tool 09-99-000-0087
(Contact US&S)
Harting tool 09-99-000-0101
-- Insertion tool, for:
48-pin, #16 to #20 wire
48-pin, #20 to #26 wire
96-pin, #20 to #28 wire
--
(Contact US&S)
(Contact US&S)
Harting tool 09-99-000-0100
-- Locator tool, for:
48-pin, #16 to #20 wire
48-pin, #20 to #26 wire
96-pin, #20 to #28 wire
--
Harting tool 09-99-000-0086
(Contact US&S)
Harting tool 09-99-000-0099
6 Address Select PCB
48-pin housing
96-pin housing
N17003101
N17003301
Used to set cardfile slot address on selected PCBs.
(Replaces N17002002)
(Replaces N17002101)
