Page #31 background imageLoading...
Page #31 background image
GENISYS II System Hardware Installation UNION SWITCH & SIGNAL
SM-6900B Rev. 0.0 August 1999 2-19
2.4.2 Non-Vital I/O PCBs
The “32/32” non-vital I/O board connects all 32 of its inputs and outputs to the rear connector on
the board and uses a 96-pin connector on the rear. Specifications for the non-vital I/O PCBs are
as follows:
US&S
Part No.
Board
Name
Input and
Output Voltage
Range
Externally
Available
Inputs
Externally
Available
Outputs
Current Rating on
Outputs
N17061501 32/32 6.0 to 30.0 Vdc 32 32 Outputs 1-30: 0.25A
(polyswitch-protected)
Outputs 31, 32: 5.0A fuse*
*Suitable for lighting lamps up to 25W.
All inputs are activated from a positive voltage relative to battery negative over the 6.0 Vdc to
30.0 Vdc range. All outputs are delivered from a low-side switch, which requires that the device
under control be connected from an output terminal to B12. Figure 2-9 shows the generic
interface wiring for this board.
