UNION SWITCH & SIGNAL GENISYS II System Hardware Installation
4-2 August 1999 SM-6900B Rev. 0.0
4.2.2 PCB Interface Cable Assembly Components and Tools*
Item/Description US&S Part No. Comments*
48-Pin Connector Assembly J709146-1105 Used with all PCBs except N17061501.
96-Pin Connector Assembly J709146-1104 Used with non-vital I/O PCB N17061501.
48-Pin Connector Receptacle J709146-0452 --
96-Pin Connector Receptacle J709146-0922 --
Receptacle Mounting Screw J525400-0001 48-pin or 96-pin receptacle
48-Pin Guide J709146-1106 --
96-Pin Guide J709146-1107 --
Wire Crimp Contacts J709146-0453 48-pin, #16-#20, (Harting # 09-06-000-8482)
J709146-0853 48-pin, #20-#26 (Harting # 09-06-000-8481)
J709146-0921 96-pin, #20-#28 (Harting # 09-06-000-8484)
Address Select PCBs N17003101 48-pin housing (Replaces N17002002)
N17003301 96-pin housing (Replaces N17002101)
EEPROM PCB N17002001 CPU PCB connector assembly only.
Crimp Tools -- 48-pin, #16-#20 (Harting # 09-99-000-0077)
-- 48-pin, #20-#26 (Harting # 09-00-000-0076)
-- 96-pin, #20-#28 (Harting # 09-00-000-0075)
Extraction Tools -- 48-pin, #16-#20 (Harting # 09-99-000-0087)
Contact US&S 48-pin, #20-#26 Wire
-- 96-pin, #20-#28 (Harting # 09-99-000-0101)
Insertion Tools Contact US&S 48-pin, #16-#20
Contact US&S 48-pin, #20-#26
-- 96-pin, #20-#28 (Harting # 09-99-000-0100)
Locator Tools -- 48-pin, #16-#20 (Harting tool 09-99-000-0086)
Contact US&S 48-pin, #20-#26
Contact US&S 96-pin, #20-#28 (Harting tool 09-99-000-0099)
* Reference Section 2.3 and Figure 2-6 for parts locations.
4.2.3 Misc. Cardfile Installation Parts
Item/Description US&S Part No. Comments
PCB Keying Plug J709146-0473 Reference Section 2.2.2 for installation.
L.H. Cardfile Mounting Bracket M451811-4501 Included with cardfile.
R.H. Cardfile Mounting Bracket M451811-4502 Included with cardfile.
