GENISYS II System Hardware Installation UNION SWITCH & SIGNAL
SM-6900B Rev. 0.0 August 1999 4-3
4.3 POWER/SIGNAL CONDITIONING AND PROTECTION EQUIPMENT
Item/Description US&S Part No. Comments
Metal Oxide Varistor J582324 Application: Cardfile system power input
Reference Section 2.1.3.2 and Figure 2-2.
Equivalent: GE V131DA40 or Siemens B40K130.
Transient Voltage Suppressor J792736-0032 Application: Cardfile system power input
Reference Section 2.1.3.2 and Figure 2-2.
Equivalent: 5KP36A.
4.4 MISCELLANEOUS UNIT INSTALLATION HARDWARE
Item/Description US&S Part No. Comments
Power-Off Relay Reference Section 3.1.
Relay J726153-0283 --
Base J581782-0026 --
Spring Clip J680167-0009 --
Serial Communication Adapter Panel Reference Section 3.3.
Nut J480203 --
Screw, #12-24 x 1/2 P-head J507261 --
Washer, #12 lock J047750 --
