Chapter 4 Installation Guide
4.1 Unpacking
Check that the received equipment is in accordance with the packing list. Ensure that the
cabinet and the equipment have not been damaged during transportation.
Report any parts that are damaged, missing or incorrect. If possible, correct the problem
before continuing.
4.2 Tools
The following tools are required for a safe installation of the system:
• Anti-static hand strap.
• Socket wrench, insulated.
• Screwdriver set, at, insulated.
• Screwdriver set, torx, insulated.
• Screwdrivers, pozidrive (cross head), sizes 1, 2, and 3, insulated.
• Torque spanner (for battery connection), insulated.
WARNING Use only single-ended, fully insulated tools. Shafts of for example screwdrivers
should be insulated.
CAUTION Installation in USA / Canada must conform with the requirements in
NEC/CEC.
CAUTION Care must be taken when installing this system. The units can be damaged
and can cause damage if not handled with care. Pay particular attention to the order in
which units are installed.
4.3 Rack Mounting
NOTE For ease of mounting the power rack it is recommended to remove the rectiers.
The power system is designed for 19”/ETSI mounting to a cabinet or an open frame. The
mounting brackets on the sides of the power system t the chassis in three dierent positions
for various mounting depth.
See appendix A for detailed dimensional Drawings.
