Chapter 7 Replacing Modules
7.1 Controller Replacement
A faulty Controller can be easily replaced with a new one:
1. Loosen the front screw in the top left corner of the controller front panel using a at
screwdriver, see Figure 7-1.
Figure 7-1 Unlocking the Controller
2. Pull the controller out of the shelf as shown in Figure 7-2.
Figure 7-2 Removing the Controller
3. Reverse the process to insert the new controller into the empty slot and fasten the screw.
CAUTION After controller start-up, verify if the appropriate conguration le is uploaded
to the controller. If necessary refer to the PowCom™ User Guide.
