2.2 System Parameters
OUTPUT
Power (max) 4800W (XPGe12.48G), 3200W (XR08.48G), 1600W (XR04.48G)
Output Current (max) 60A @ 55°C (XPGe12.48G & XR08.48G)
30A @ 55°C (XR04.48G)
Voltage 46-57VDC
INPUT
Voltage 1-phase 100-120/200-240VAC (L + N + PE)
3-phase 230/400VAC (L1 L2 L3 + N + PE)
Frequency 47-63Hz
Input Current 1-phase 32A @ 100-120VAC, 14A @ 200-240VAC
3-phase 8A per phase @ 230/400VAC
Power factor >0.98
Surge Protection Optional
DC DISTRIBUTION & BATTERY MANAGEMENT
Battery Breakers 2 x 30A, 45A, 60A, 80A or 100A
Symmetry Inputs Up to 6
Programmable LVD / PLD 125A (voltage) / 125A (voltage/time)
Load Breakers 8 x (NADER NDB3 Series)
Ratings* 1A, 4A, 5A, 7.5A, 10A, 15A, 20A, 25A, 30A
MONITORING AND CONTROL
Controller PCC or ACC Extended
Local Interface 4 x 20’ LCD, 4-key menu, USB (ACC only) and RS232
Remote Interface Ethernet / Modem using PowCom™ software
Visual Indication Green LED - System On
Yellow LED - Message(s)
Red LED - Alarm(s)
Analog Inputs 12 x voltage inputs (range 0-100VDC) - 6 max. for symmetry
Alarm Outputs 4 x potential free relays (C, NC, NO)
Digital Inputs 2 x, Logic 0: U<10VDC, Logic 1: U>12VDC (ACC only)
Digital Outputs 2 x, open collector type (ACC only)
Temperature measurement 2 x Temperature probe (Battery, Ambient)
CONNECTIONS
Battery connections M6 lugs, +Ve common from bus bar
AC connections Max. 9AWG/6mm
2
, screw type connector
Load breaker connections +Ve termination direct to breakers, +Ve common from busbar
11AWG/4mm²
Alarm connections Max. 14AWG/1.5mm², screw type connector
