UNIRAC EcoFoot2+ - Strut Installation Notes

INSTALLATION GUIDE
PAGE
21
10-DEGREE BALLASTED RACKING SYSTEM
1. As per the array layout plan, Strut attachment locations may cover one, two or more modules per attachment location. Strut length and number of connected
modules are specied on the array layout. Strut may need to be cut to meet the attachment requirements in the project’s Layout Plan or engineering report.
2. Note that EcoFoot5D ballast trays will not be installed where strut is located.
UNIRAC proudly offers dedicated engineering expertise and superior customer support. For questions about the installation procedures or a specic application,
please visit our website: www.unirac.com.
STRUT INSTALLATION NOTES
FIELD SUPPORT CONTACT INFORMATION
ROOF ATTACHMENT WITH STRUT
