MS852B Plus User’s Manual
2.32.2 Add a Data Format
Step 1.Scan the Enter Data Format symbol.
Step 2.Select Primary/Alternate FormatDetermine if this will be your primary
data format, or one of 3 alternate formats. This allows you to save a
total of 4 different data formats. To program your primary format, scan 0
using the Programming Chart
inside the back cover of this manual. If
you are programming an alternate format, scan 1, 2, or 3, depending on
which alternate format you are programming. (See "Primary/Alternate
Data Formats" for further information.)
Step 3.Terminal TypeRefer to Terminal ID Table and locate the Terminal ID
number for your PC. Scan three numeric bar codes on the inside back
cover to program the scan engine for your terminal ID (you must enter
3 digits). For example, scan 0 0 3 for an AT wedge.
Note:099 indicates all terminal types.
Step 4. Code I.D.In the Symbology Charts, beginning on page A-1, find the
symbology to which you want to apply the data format. Locate the Hex
value for that symbology and scan the 2 digit hex value from the
Programming Chart
.
If you wish to create a data format for all symbologies, with the
exception of some specific symbologies, refer to B8. If you are creating
a data format for Batch Mode Quantity, use 35 for the Code I.D.
Note:99 indicates all symbologies.
Step 5.LengthSpecify what length (up to 9999 characters) of data will be
acceptable for this symbology. Scan the four digit data length from the
Programming Chart. For example, 50 characters is entered as 0050.
Note:9999 indicates all lengths.
Step 6.Editor CommandsRefer to Data Format Editor Commands. Scan the
symbols that represent the command you want to enter. 94
alphanumeric characters may be entered for each symbology data
format.
Step 7.Scan Save to save your data format, or Discard to exit without saving
your changes.
