Unitech PA500 User Manual

Unitech Electronics Co., Ltd Created
by Yukiko
PA500 Operation
Manual
V2.0 Page 45 of 123
Allow connection between terminal and other devices.
Path:\Start\Programs\ActiveSync
Connect the terminal to your device by USB or IrDA Connection. The ActiveSync
will automatically connect the terminal and the device and start sync.
1. Double tap “ActiveSync”. Tap “Sync” to synchronize manually.
2. On “Menu”, select “Options”, select the items that you want to sync.
3. On “Menu”, select “Connections”, check “Synchronize all PCs using this
connection”. Select USB or baud rate default.
4. On “Menu”, select “Connection via IR”. Face the IrDA port to the IrDA port of
your host. Terminal is connected to host via IrDA.
Connect ActiveSync via Bluetooth
A. Bluetooth ActiveSync
A1 Check or define your host’s Bluetooth COM port
A1.1 If your host (PC or notebook) has built in Bluetooth function, turn on(Or
Enable) the Bluetooth function.

Unitech PA500 Specifications

System Memory

SDRAM	64 MB
Flash ROM	64 MB

Display

display resolution	240x320 QVGA
display type	Color Transflective TFT
touch screen	yes

Laser Bar Code Scanner

scan rate	104 scans/sec ± 12 scans/sec
scan angle default	47°±3°
scan angle reduced	35°±3°

Power

main battery voltage	3.7 V
main battery capacity	2200 mAh
rechargeable time	3.5 hours

Operating Environment

operating temperature	32°F to 122°F (0°C to 50°C)
storage temperature	-4°F to 140°F (-20°C to 60°C)
relative humidity	5% ~ 95% (non-condensing)

Weight and Dimensions

weight with battery and scan engine	Under 213 g
length	126 mm
height	23 mm
