Unitronics UniStream 5 inch - Page 4

UniStream
®
5"
4
Unitronics
Installation Space Considerations
Allocate space for:
 the controller
 any modules that will be installed
 access to ports, jacks, and the microSD card slot
For exact dimensions, please refer to the Mechanical Dimensions shown below.
Mechanical Dimensions
5” Panel
NOTE
Allow space for modules to be snapped onto the back of the controller, if required by
your application. Modules are available by separate order.
