Apollo Twin Hardware Manual Chapter 4: Specifications 28
DIGITAL INPUTS
S/PDIF
Connector Type Optical TOSLINK JIS F05 (shared with ADAT)
Format IEC958
Supported Sample Rates (kHz) 44.1, 48, 88.2, 96
S/PDIF Input Channels Two (Stereo L/R)
ADAT
Connector Type Optical TOSLINK JIS F05 (shared with S/PDIF)
Format ADAT Digital Lightpipe with S/MUX
Supported Sample Rates (kHz) 44.1, 48, 88.2, 96, 176.4, 192
ADAT Input Channels @ 44.1 kHz, 48 kHz 1 – 8
ADAT Input Channels @ 88.2 kHz, 96 kHz 1 – 4 (S/MUX)
ADAT Input Channels @ 176.4 kHz, 192 kHz 1 – 2 (S/MUX)
Clock Synchronization Sources
Internal, S/PDIF, ADAT (digital clock sync source conditional per selected digital input type)
ELECTRICAL
Power Supply External AC to DC
AC Connector Type Changeable blades (UL, VDE, UK, SSA, CCC)
AC Requirements 100V – 240V AC, 50 – 60 Hz
DC Connector Type Male plug, 2.1 mm x 5.5 mm, center positive
DC Requirements 12 VDC, ±5%
Maximum Power Consumption 12 Watts
ENVIRONMENTAL
Operating Temperature Range 32º to 95º Fahrenheit (0º to 35º Celsius)
Storage Temperature Range –40º to 176º Fahrenheit (–40° to 80º Celsius)
Operating Humidity Range 20% to 80%
MECHANICAL
Dimensions
Width 6.31”
Height 2.60”
Depth, Chassis Only 5.86”
Depth, Including Knob & Jack Protrusions 6.20”
Shipping Box (Length x Width x Height) 8” x 8” x 5.5” (20.32cm x 20.32cm x 13.97cm)
Weight
Shipping Weight (with box & accessories) 3.85 pounds
Weight (bare unit) 2.35 pounds
Package Contents
Apollo Twin Unit (SOLO or DUO)
External Power Supply with (4) changeable AC connectors supporting USA, Europe, UK, Australia, China
Getting Started URL Card
