Universal Audio Apollo Twin User Manual

Apollo Twin Hardware Manual Chapter 4: Specifications 29
Hardware Block Diagram
APOLLO TWIN HARDWARE BLOCK DIAGRAM
V05
HI-Z IN
+48V
MIC IN 1
MIC PAD
IN/OUT
+48V ON/OFF
INPUT GAIN
10 – 65 dB
ANALOG INPUTS
PAD
1M
HI-Z/MIC
SELECT
A/D
LINE IN 1
PAD
D/A
+4dBu / -10dBV
SELECT
ANALOG OUTPUTS
PAD
LINE OUT 3
D/A
MON OUT L
D/A HEADPHONES OUT
SHARC®
DSP
DRAM
SHARC®
DSP
DRAM
ARM®
PROCESSOR
XLR FEMALE
1/4”
1/4” TRS
1/4” TRS 1/4” TRS 1/4” TRS
MIXER
CLOCKING / SYNC
SYSTEM CONTROL
ø
LOW-CUT
ON/OFF
POLARITY
CONTROL
OPTO
OUTPUT
VOLUME
HI-Z/MIC-LINE
SELECT
OPTICAL INPUT
FRONT PANEL
THUNDERBOLT
TM
HOST INTERFACE
+48V
MIC IN 2
MIC PAD
IN/OUT
+48V ON/OFF
INPUT GAIN
10 – 65 dB
PAD
A/D
XLR FEMALE
LINE IN 2
PAD
1/4” TRS
ø
LOW-CUT
ON/OFF
POLARITY
CONTROL
MIC/LINE
SELECT
DSP DSP
+14dBu / +20dBu
SELECT
PAD
D/A
MON OUT R
1/4” TRS
OUTPUT
VOLUME
PAD
D/A PAD
LINE OUT 4
1/4” TRS
D/A
EEPROM
+4dBu / -10dBV
SELECT
+14dBu / +20dBu
SELECT

Universal Audio Apollo Twin Specifications

General

Type	Audio Interface
Phantom Power	Yes
A/D Resolution	24-bit
DSP	Yes
Number of Preamps	2
Line Inputs	2
Line Outputs	2
Output Channels	6
Monitor Outputs	2
Analog Outputs	2 TRS
Headphones	1
Sample Rates	44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
Operating System	Mac, Windows
Preamps	2
DSP Processing	Yes
Connectivity	Thunderbolt
Analog Inputs	2 XLR/TRS combo
