Universal Laser Systems ULS-25 - Appendix B: Laser System Specifications

B
APPENDIX B - LASER SYSTEM SPECIFICATIONS
Model Number ULS-25
Maximum Engraving Area 17" x 11.5"
Maximum Engraving Speed 16.5"/second
Laser Source 25 Watt C0
2
Laser Beam Diameter
- Standard Optics 0.007"
- High Resolution Optics (Optional) 0.003"
Repeatability +/- 0.002"
Interfaces Parallel = Centronics
Serial = RS-232C
Buffer Memory Size 4MB (upgradeable to 16MB)
System Dimensions 37" x 30" x 38"
System Weight 170 lb.
Safety Classification Class I
Focal Plane (Z axis) Adjustment 6.25"
Facility Requirements
Electrical Power: Single phase, 120 VAC, 50/60 Hz, 10 Amp
Exhaust: 235 CFM minimum at 6 inches of static pressure
Cooling: Air cooled ambient temperature between 60 and 78 degrees Fahrenheit
Specifications are subject to change without notice.
