Universal Robots UR3e

2. Remove the 18 bolts connecting the front frame to the back plate using a T8 Torx
screwdriver.
3. Pull the front frame and back plate apart. This will in some cases require some force but
note that there is a cable connecting the two parts, be careful that this cable or connectors
does not get damaged.
Service Manual 65 e-Series
