Page 8.2
DRIVE ASSEMBLY
FIGURE 14
ILLUS. No. PART No. DESCRIPTION QTY.
1 1064504 Lower Vari-Speed Pulley 1
2 1064503 Upper Vari-Speed Pulley 1
3 1064505 Drive Belt (SRM60) 1
1080035 Drive Belt (SRM80) 1
4 1064520 Motor, 3HP, 208-240V, 60HZ, 1PH 1
1064522 Motor, 3HP, 208-240/460V, 60HZ, 3PH 1
1064521 Motor, 3HP, 220-240V, 50HZ, 1PH 1
1064523 Motor, 3HP, 220/380/440V, 50HZ, 3PH 1
1064524 Motor, 3HP, 200V, 50-60HZ, 3PH 1
3
1
2
4
