The electronic control board is already set with the
cooling program (COOL) and the cooking chamber
washing programs (L1, L2, L3, LH20), for use with
the automatic washing system XC404 if connected.
Program setting - by the user
To set a program proceed as follows:
• the first display shows “Prg”, by pushing but-
ton it is possible to select the type you need to chan-
ge; to change the type push buttons.
• push button and the first display on your
left will show “PRE” message and all the 4 step
leds turns off. By pushing button, you set
the temperature as absolute value or as difference:
the backlighted chamber temperature icon or the
backlighted Delta T icon turns on, and you can set
the required value by pushing
but-
tons.
• select the required cooking settings (time, core
temperature, cavity temperature, Delta T, clima-
te); as for manual working, every cooking pro-
gram can be composed by 1 to 4 steps
• to save the program press and hold the
button for 5 seconds (after 5 seconds have pas-
sed you will hear a bleep) the program is now
saved.
Use of saved programs, cooling pro
-
gram
To call up a program saved by the user, the cooling
program or a washing program follow the procedu-
re below :
• enter program mode by touching the button
• select the required program by touching the but-
tons
• start the selected program by touching the but-
ton
• when the selected program starts, the led “START
ENGLISH
7
ENGLISH
6
ENGLISH
STOP” turns on
• while the cooking program is in operation it is not
possible to modify the program settings.
• it is possible to stop the program by touching the
button
When you start the cooking program, the oven starts
the pre-heating phase: the cooking chamber is hea-
ted up to 30°C more than the chamber temperatu-
re originally set in the first cooking step. While the
pre-heating phase is on, all the leds and display pa-
nels remain turned off apart from: “START / STOP”
led, the display panel 1 which shows the message
“PRE”, and the display panel 3 which shows the se-
lected program. When the required temperature is
reached (step 1 chamber temperature + 30°C) the
oven will make a continuous audible bleep and the
display panels show the settings of the first cooking
step. After you’ve opened the door of the oven,
loaded the food and closed the door, the cooking
program automatically starts.
Once the cooking cycle is finished, both in manual
and programmed mode, if you push “P” button the
5 types display will show “LASTP” message: by pu-
shing “START / STOP” button last cooking cycle
that was used will start again.
Washing programs
The control board is pre-set with 3 washing pro-
grams (L1 short, L2 medium, L3 long) + a rinsing
program LH2O + a program for the pre-loading of
the detergent and rinse aid pumps. (LPUMP).
Cooking chamber cooling down program
“COOL”
“COOL”, this program is used for cooling down the
cooking chamber, it allows the fans inside the chamber
to rotate whilst the heating elements remain off. The
program works also with the door of the oven open.
While “COOL” program is working, the display shows
cooking chamber temperature.
Important!
It is not possible to remove the fan guard without
the proper removal tool, thanks to the presence of
a fixing screw. If it is necessary to remove the fan
guard for service, do not forget to disconnect the
appliance from the electrical supply.
