UP mini 2 User Manual

Prepare for Printing - Update Nozzle Height
The printer was calibrated before leaving the factory, but users are recommended to
update the nozzle height value using the automatic nozzle height detection function
on the touch screen before the first print.
Press “Calibrate” button to enter Nozzle
Height setup page.
Press the “Auto” button to start the
automatic process.
During nozzle height detection, the
print head nozzle will touch the nozzle
detector to make measurement.
128
Auto
14

UP mini 2 Specifications

General

Build Volume	120 x 120 x 120 mm
Filament Diameter	1.75 mm
Nozzle Diameter	0.4 mm
Print Material	ABS, PLA
Connectivity	USB, Wi-Fi
Heated Bed	Yes
Enclosure	Yes
Touchscreen	Yes
Print Technology	FDM (Fused Deposition Modeling)
Print Speed	Up to 100 mm/s
Power Requirements	100-240V, 50-60Hz
Weight	8 kg
