UP mini 2 User Manual

Printing Parameters
Surface
Infill
Support
Raft
Surface
Dense (support)
Print Platform
Support Range: < 30
o
Support Range: < 90
o
Dense: Solid support structure ensures that the surface being supported retains its
shape and surface finish.
Infill: The inner structure of the printed object. The density of the infill can be adjusted.
Raft: The thick structure that assists with the adhesion of the object to the platform.
Surface: The top and bottom layers of the printed object.
41

UP mini 2 Specifications

General

Build Volume	120 x 120 x 120 mm
Filament Diameter	1.75 mm
Nozzle Diameter	0.4 mm
Print Material	ABS, PLA
Connectivity	USB, Wi-Fi
Heated Bed	Yes
Enclosure	Yes
Touchscreen	Yes
Print Technology	FDM (Fused Deposition Modeling)
Print Speed	Up to 100 mm/s
Power Requirements	100-240V, 50-60Hz
Weight	8 kg
