UPERFECT MDS-156F13 - Gaming and Mini Host Connections; Mini Host HDMI Connection; PS4 HDMI Connection

Function introduction Function introduction
Rotate ± 90 °
Rotate 180 °
6. Connect to Mini Host with HDMI interface
Duplicate Mode
Type-C to USB 3.0(For Touch)
Type-C to USB 3.0(For Touch)
Mini HDMI to HDMI
(Video/Audio signal)
Mini HDMI to HDMI (Video/Audio signal)
Type-C to USB 3.0(For Touch)
Mini HDMI to HDMI
(Video/Audio signal)
Front
Rotate ± 90 °
Rotate 180 °
7. Connect to Gaming device with HDMI interface
PS4
Mini HDMI to HDMI (Video/Audio signal)
Mini HDMI to HDMI (Video/Audio signal)
Mini HDMI to HDMI (Video/Audio signal)
Front
Note: The touch function can’t be achieved by PS4.
14 15
