Upright MB26 - Control Functions Explained

Page 8
4 O PERATION OF THE P LATFORM C ONTROLS
C ONTROL F UNCTIONS
I TEMS N AMES F UNCTION
1 Joystick
Refer to the decal logic diagrams for correct direction of
motion.
e.g. If Drive is preselected - pushing forward moves
machine forward.
2 Deadman Grip
The ‘Deadman’ grip switch on the joystick must be
grasped for any function to operate.
3 Emergency Stop
Push this red button at any time to isolate power.
Turn clockwise to reset.
4 Steering Switch Turns the wheels left or right.
5 Jib Select Button Pre-selects the Jib function.
6 Mast Select Button Pre-selects the Mast function.
7 Rotate Select Button Per-selects the Mast Rotate function.
8 Drive (Mast Raised)
Pre-selects the drive function with the mast in the raised
position and for high torque. (i.e. slow speed)
9 Drive (Mast Lowered)
Pre-selects the drive function with the mast in the
lowered position. (i.e. maximum speed)
10 Key Switch
Activates (ON) and De-actives (OFF) all machine
functions.
11 Horn Button Use to warn bystanders or to attract attention.
12 Multi-Function Display Displays the Percentage battery life. (99=Full, 01-Empty)
Table 1: Platform Controls and Indicators
