Page 20
S
PECIFICATIONS
S
PECIFICATIONS
MB20
N
P
ARAMETER
MB20
N
EU V
ERSION
MB20
N
US V
ERSION
Duty Cycle
Platform Size
Maximum Platform Capacity
Maximum No. of Persons
45%over 8 hour cycle
780mm x 745mm
215kg.
2
35%over 8 hour cycle
31in. x 29in.
425lbs.
2
Heights:
Maximum Platform Height
Maximum Working Height
Platform Height at Maximum Outreach
6.00m
8.00m
5.04m
19.69ft.
26.25ft.
16.54ft.
Maximum Working Outreach
2.64M 8.66ft.
Stowed Dimensions:
Length
Width
Height
2.222m
0.815m
1.990m
7.97ft.
32in.
6.50ft
Chassis Ground Clearance
Wheelbase x Wheel Gauge
Rotation
Gross Vehicle Weight
Maximum Drive Speed - Stowed
Maximum Drive Speed - Elevated
Maximum Gradeability
Outside Turning Radius
90mm
1465mm x 708mm
360deg non-continuous
2570kg.
3.03 km/h
0.70km/h
25%
1.85m
3.54in.
4.81ft. x 2.32ft.
360 deg non-continuous
6674lbs.
1.9mph.
0.43mph
25%
6.10ft.
Electrical:
Power Source
System Voltage
Battery Charger
Control System
4 x 6V @ 375Ah Battery
24 Volt DC
24V x 30A, 220V 50Hz AC
Single Joystick, Function
Selector, DC Motor Controller
4 x 6V @ 375Ah Battery
24 Volt DC
24V x 30A, 110V 60Hz AC
Single Joystick, Function
Selector, DC Motor Controller
Hydraulic System:
System Relief Setting
Hydraulic Oil Type
Hydraulic Tank Capacity
Brakes
220bar
ISO VG46
20 litres
Spring applied hydraulically
released
3190psi
ISO VG46
5.3 gallons (U.S.)
Spring applied hydraulically
released
Wheel & Tyres 13.5in. x 4.0
solid, Non-Marking
13.5in. x 4.0
solid, Non-Marking
Noise Pressure Level
68dB (A) at Control Station 68dB (A) at Control Station
