110 “Translation of the original instruction”
Pic.20(Some same as Pic.1)
B SYSTEM SCISSOR LIFT
Connect
light-emitting diode
Top Height Limit
2m Stop
Pothole Guard
High Speed
Forward
Up
Turn Left
High Speed
Backward
Turn Right
6 Core Wiring
16 Core Male Plug
Totally 8 pages
The Seventh Page
B System Wiring Diagram
