Upright MX Series User Manual

112 “Translation of the original instruction”
Pic.21(Some same as Pic.1)
A System Scissor Lift Explanation
Relay
16 Core Female Plug
Fast Connect 1
Note: 1. All the wiring is
0.75mm2
2. Hour meter has its own Connect
Key Switch
Hour Meter
Toggle Switch
Connecting wiring 5
Emergency Stop Button
Beeper
Totally 8 pages
The eighth Page
B System Ground control Wiring
Qty

Upright MX Series Specifications

General

Lift Capacity	500 lbs
Weight Capacity	500 lbs
Platform Width	30 in
Overall Width	36 in
Overall Length	8 ft
Stowed Length	8 ft
Stowed Width	36 in
