Specifications
S
PECIFICATIONS
*Specifications are subject to change without notice. Hot weather or heavy use may affect performance.
Refer to the Parts Manual and the Service Manual for complete parts and service information.
The MX15 / MX19 meets or exceeds all applicable requirements of OSHA and ANSI A92.6-1999.
ITEM MX15 MX19
Gross Vehicle Weight (machine + rated load) 1,592 kg (3510 lbs.) 1692 kg (3730 lbs.)
Maximum Wheel Load 315 kg (1050 lbs.) 345 kg (1150 lbs.)
Platform Size (Inside minimum) 0,72 m x 2,5 m (28.5 in. x 100 in.)
Maximum Platform Capacity 250 kg (550 lbs.) 227 kg (500 lbs.)
Maximum Number of Occupants
Standard w/Deck Extension
2 People
on Extension
1 Person
Height
Working Height
6,57 m (21 ft.) 7,79 m (25 ft.)
Maximum Platform Height
4,57 m (15 ft.) 5,79 m (19 ft.)
Minimum Platform Height
0,90 m (35.5 in.)1,02 m (40.25 in.)
Dimensions
Weight
1343 kg (2960 lbs.) 1465 kg (3230 lbs.)
Overall Width
0,76 m (30 in.) 0,76 m (30 in.)
Overall Height (Lowered)
1,89 m (74.5 in.) 2,01 m (79.25 in.)
Overall Length (Deck in)
1,75 m (68.75 in.) 1,75 m (68.75 in.)
Overall Length (Deck extended)
2,71 m (106.5 in.) 2,71 m (106.5 in.)
Drivable Height 4,57 m (15 ft.) 5,79 m (19 ft.)
Drive Speed
Platform Lowered
3,7 km/h (2.3 mph)
Platform Raised
1,0 km/h (0.62 mph)
Energy Source 24 Volt Battery Pack (four 220 A hour, 6 Volt batteries, min. wt. 26,3 kg [58 lbs.] each)
Motor 24 Volt 4 Horse Power DC Electric Motor
System Voltage 24 V DC
Battery Charger 20 A, 110/220 VAC
Hydraulic Reservoir Capacity 12,9 L (3.4 US gal.)
Maximum Hydraulic System Pressure 207 bar (3000 psi)
Hydraulic Fluid
Normal above 32° F [0° C]
ISO #32
Low Temp. below 32° F [0° C]
ISO #32
below 0° F [-17° C]
ISO #15
Lift System One Single Stage Lift Cylinder
Lift Speed
Lift, 19 sec.
Lower, 20 sec.
Lift, 19 sec.
Lower, 18 sec.
Control System • Proportional Control Handle with Interlock Switch
• Rotary Lift/Drive Switch
• Red Mushroom Emergency Stop Switch
Drive System Dual Front Wheel Hydraulic Motors
Tires 305 mm (12 in.) diameter solid rubber, Non-marking
Parking Brake Dual, Spring Applied, Hydraulic Release
Turning Radius
Inside: 152 mm (6 in.)
Outside: 1,6 m (64 in.)
Maximum Gradeability 29% (16°)
Wheel Base 1,24 m (49 in.)
Guardrails 1,10 m (43 in.)
Toeboard 152 mm (6 in.)
Ground Clearance 9 cm (3.5 in.)
