Hydraulic Section 4 - Schematics
Page 4-12 113101-000 MX15 / MX19 | Service Manual
Figure 4-11:
Cylinders
SOL3B & V3B
Depression Mechanism
Retract Solenoid and Valve
OR1
Orifice (beveled side toward cylinder block)
Depression Mechanism Cylinder
Steering Cylinder
Lift Cylinder
V2B Manual Emergency Lowering Valve
