USC LPX 2000 - Page 123

Page 123
LPX SEED TREATER
CSA COMPLIANT MAIN CONTROL PANEL ASSEMBLY (13-12-0119)
Item # Part #
Description Qty
1 03-12-0367
MAIN CONTROL PANEL U-TREAT 1
2 05-03-1471 ASSY PNL FRM 4PUMP SAP 1
3 06-01-0124 BOLT, FLG .375-16 UNC ZP GRADE 5; 3/4" LG 4
4 06-01-0220 BOLT .375-16 X 3.75 CONCRETE ZP 4
5 06-03-0033 NUT LOCK FLG .375-16 GR8 4
THIS MATERIAL IS THE CONFIDENTIAL AND PROPRIETARY PROPERTY OF
USC, LLC. AND SHALL NOT BE USED WITHOUT PERMISSION.
THIS MATERIAL IS THE CONFIDENTIAL AND PROPRIETARY PROPERTY OF
USC, LLC. AND SHALL NOT BE USED WITHOUT PERMISSION.
± 1/16
.XX=±.03
.XXX=±.005
.XXXX=±.0005
±0.50°
DRAWN
CHECKED
ENG APPR
NAME
davidw
DATE
07/29/2014
TITLE
SIZE
D
DWG NO
File Name:13-12-0118 = MCP Automation Pkg.dft
SHEET 1 OF 1
UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN
INCHES:
TOLERANCES:
FRACTIONS DECIMALS ANGLES
DO NOT SCALE DRAWING
U S C, L L C.
Sabetha, Kansas 66534 USA
Printed 07/29/14 at 9:22
REV
± 1/16
.XX=±.03
.XXX=±.005
.XXXX=±.0005
±0.50°
DRAWN
CHECKED
ENG APPR
NAME
davidw
DATE
07/29/2014
TITLE
SIZE
D
DWG NO
File Name:13-12-0118 = MCP Automation Pkg.dft
SHEET 1 OF 1
UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN
INCHES:
TOLERANCES:
FRACTIONS DECIMALS ANGLES
DO NOT SCALE DRAWING
U S C, L L C.
Sabetha, Kansas 66534 USA
Printed 07/29/14 at 9:22
REV
REVISION HISTORY
REV ECN DESCRIPTION DATE BY
A INITIAL DRAWING
Item # Part # Rev Title Qty
1 03-12-0366 A MAIN CONTROL PANEL U-TREAT 1
2 05-03-1471 A ASSY PNL FRM 4PUMP SAP 1
3 06-01-0124 A BOLT, FLG .375-16 UNC ZP GRADE 5; 3/4" LG 4
4 06-01-0220 A BOLT .375-16 X 3.75 CONCRETE ZP 4
5 06-03-0033 A NUT LOCK FLG .375-16 GR8 4
3
1
5
2
4
