REVISION HISTORY
REV ECN DESCRIPTION DATE BY
A INITIAL DRAWING
Item # Part # Rev Title Qty
1 03-12-0366 A MAIN CONTROL PANEL U-TREAT 1
2 05-03-1471 A ASSY PNL FRM 4PUMP SAP 1
3 06-01-0124 A BOLT, FLG .375-16 UNC ZP GRADE 5; 3/4" LG 4
4 06-01-0220 A BOLT .375-16 X 3.75 CONCRETE ZP 4
5 06-03-0033 A NUT LOCK FLG .375-16 GR8 4
1
5
2
4
3
