AUTOMATIC CHLORINATOR - 3000LB/24HR
49
d. Remove diaphragm (6). Remove machine screws (4). Remove
and discard gaskets (7).
Reassembly
a. Refer to the cleaning procedure and clean the parts prior to reas-
sembly.
b. Wipe a thin film of Halocarbon grease onto all O-rings.
c. Reassemble in the reverse order of disassembly.
4.12.5 Vacuum Gauges
CAUTION: Do not disassemble diaphragm unit from vacuum gauge.
4.12.6 Adjustment of V-Notch Plug Linkage
When the controller is receiving a zero flow signal, loosen the hex nut at
the top of the rack in the control module and rotate the coupling screw until
the V-notch plug is at its zero position (see Dwg. 25.200.150.010). Tighten
the hex nut.
4.12.7 Troubleshooting
The following troubleshooting table is provided for determining and cor-
recting most common troubles.
!
