USX-MOUNT XML019 - Product Dimensions

TV INTERFACE
3-D
WALL PLATE
FULLY ASSEMBLED MOUNT TOP VIEW - RETRACTED
TOP VIEW - EXTENDED SIDE VIEW - EXTENDED
3
+5°
-15°
412.1mm
[16.22in]
175.7mm
[6.92in]
236mm
[9.29in]
9mm
[0.35in]
64mm
[2.52in]
422mm
[16.61in]
SIDE VIEW - EXTENDED
+45°
679mm
[26.73in]
420mm
[16.54in]
435mm
[17.13in]
285mm
[11.22in]
200mm
[7.87in]
600mm
[23.62in]
400mm
[15.75in]
15mm
[0.59in]
Dimensions
