2L0
2-2-2
List of correspondences of PWB names
No. Name used in service manual Name used in parts list
1 Control PWB PARTS PWB CONTROL SP
2 Power source PWB SWITCHING REGULATOR 120V
SWITCHING REGULATOR 230V
3 High voltage PWB PARTS HIGH VOLTAGE UNIT SP
4 Operation panel PWB PARTS PWB LCD SP
5 APC PWB -
6PD PWB -
7 Zener PWB -
8 Eraser lamp PWB -
