Utax LP 3335 - Printing an Event Log (EVENT LOG)

2L0
1-3-9
(3) Printing an event log (EVENT LOG)
Service items Description
Printing an event log
(EVENT LOG)
Printing an event log (EVENT LOG)
Description
Prints a history list of occurrences of paper jam, self-diagnostics, toner replacements, etc.
Purpose
To allow machine malfunction analysis based on the frequency of paper misfeeds, self diag-
nostic errors and replacements.
Procedure
1. Connect the USB or network cable between printer and PC (network).
2. Connect the power cord.
Figure 1-3-4
3. Turn printer power on. Make sure the printer is ready.
4. Send the following PRESCRIBE command sequence from the PC to the printer.
!R!KCFG"ELOG";EXIT;
Note: To send a PRESCRIBE command sequence to the printer, use COMMAND
CENTER (the printer's embedded web) while the printer is connected to the PC via its
network interface.
A sheet of event log will be printed.
Completion
Network cable
USB cable
USB interface
connector
Network interface
connector
