Setup and Registration (System Menu) > System Menu
Network Interface (Send)
[System Menu/Counter] key > [System/Network] > [Network Interface (Send)]
Custom Setup The detailed settings for wireless LAN can be changed.
Network Name (SSID) Set the SSID (Service Set Identifier) of the wireless LAN to which the machine connects.
NOTE
Up to 32 characters can be entered.
Connection Mode Set the connection mode.
Value: Ad Hoc, Infrastructure
NOTE
Ad Hoc: Directly communicates with the device without going through an access point. This
method cannot be used to connect to two or more devices.
Infrastructure: Performs communication through an access point.
Channel Set channel. Use [-] / [+] or the numeric keys to enter a number.
Value: 1 to 11
Network Authentication Select network authentication type. To select other options, open the device home page from a
computer.
Value: Open, Shared, WPA-PSK
*1
, WPA2-PSK
*1
Encryption Select encryption method. If the option other than [Disable] is selected, enter the WEP key or
the Preshared key. The setting values vary depending on the Network Authentication setting.
Select [Data Encryption].
When Network Authentication is set to [Open] or [Shared]
Value: Disable, WEP
When Network Authentication is set to [WPA-PSK] or [WPA2-PSK]
Value: TKIP
*2
, AES, Auto
*2
NOTE
If [WEP] is selected, enter the WEP key. Up to 26 characters can be entered.
If [ TKIP ], [ AES ] or [ Auto ] is selected, enter the Preshared key. Enter the value in 8 to 64 characters.
*1 Not displayed if you selected [Ad Hoc] for "Connection Mode".
*2 Not displayed if you selected [WPA2-PSK] for "Network Authentication".
NOTE
This function is displayed when the optional Network Interface Kit or Wireless Network Interface Kit is installed.
Item Description
Network Interface (Send) Specify the network interface card to be used for the send function, the network authentication
and connecting to external address book.
Value: Standard, Optional NIC
