UTC Fire and Security Edwards BPS10A/230 User Manual

Remote Booster Power Supply Technical Reference Manual 47
Genesis circuit notification
Figure 26: Genesis circuit notification
G
(1)
(2)
BP
S
(5)
(6)
(7)
(8)
G
G G
GG
G
GG
(3)
(4)
(9)
(10)
G
G G
GG
G
GG
(10)
(1)
(2)
BPS
(5)
(6)
(7)
(8)
(3)
(4)
(1) Sense 1
(2) Sense 2
(3) Mode: COR
(4) NACs: SF
(5) NAC 1
(6) NAC 2
(7) NAC 3
(8) NAC 4
(9) To BPS, or EOL resistor
(10) To next device or EOL resistor
Note: The maximum number of BPSs that can be connected on a single NAC from sense circuit
to sense circuit is limited by available current and wire run length.
DIP switch settings for this application
Each BPS DIP switch can be set this way for the application to work correctly. If
other BPS options are required, refer to “Setting the DIP switches” for more
information.
Figure 27: Switch settings
SW1 SW2
1234
5
6
7
8
ON
1234
5
6
7
8
